| Product Type |
Dirt Conveyor Belt |
| Application |
Conveying Dirt, Soil, Earth, Sand, Gravel, Construction Debris and Excavated Material |
| Belt Width |
300 mm to 2400 mm |
| Belt Speed |
0.5 to 3.5 m/s, depending on application |
| Conveying Capacity |
Application and Material Dependent |
| Inclination Angle |
Up to 18° with Smooth Belt; Higher Angles with Cleated Belt |
| Belt Construction |
EP / NN / Steel Cord Reinforced |
| Belt Strength |
As Required by Conveyor Length, Load and Operating Conditions |
| Top Cover |
Heavy-Duty Abrasion Resistant Rubber |
| Bottom Cover |
Wear Resistant Rubber |
| Cover Grade |
DIN-Y / DIN-W / Abrasion Resistant Grade |
| Belt Thickness |
As Per Belt Strength and Application Requirements |
| Material Handled |
Soil, Dirt, Earth, Sand, Gravel, Clay, Stones and Excavated Spoil |
| Operating Condition |
Heavy-Duty Construction, Mining and Earthmoving Applications |
| Abrasion Resistance |
High Abrasion Resistance for Continuous Contact with Soil, Gravel and Stones |
| Impact Resistance |
High Impact Resistance for Loading of Coarse and Irregular Materials |
| Moisture Resistance |
Suitable for Wet, Damp and Outdoor Operating Conditions |
| Drive System |
Electric Motor with Geared Drive |
| Tensioning System |
Screw Take-Up / Gravity Take-Up |
| Idler Type |
Carrying Idlers / Return Idlers / Impact Idlers |
| Splicing Method |
Hot Vulcanized Splicing / Mechanical Fasteners |
| Edge Construction |
Cut Edge / Molded Edge, as Required |
| Temperature Range |
Typically -20°C to +80°C, Depending on Rubber Compound |
| Conveyor Compatibility |
Suitable for Construction, Excavation, Mining, Landscaping and Earthmoving Conveyor Systems |
| Customization |
Belt Width, Length, Strength, Cover Thickness, Rubber Grade and Construction as per Requirement |
