| Product Type |
Trough Belt Conveyor |
| Conveyor Type |
Continuous Bulk Material Handling Conveyor |
| Belt Width |
400 mm to 2400 mm |
| Belt Speed |
0.5 to 5.0 m/s, depending on application |
| Conveying Capacity |
Application and Material Dependent |
| Troughing Angle |
20°, 30°, 35°, 45° or as required |
| Conveyor Inclination |
Typically Up to 18° with Standard Smooth Belt |
| Belt Construction |
EP / NN / Steel Cord Reinforced |
| Belt Strength |
As Required by Conveyor Length, Load and Operating Conditions |
| Top Cover |
Abrasion Resistant / Heat Resistant / Oil Resistant Rubber, as Required |
| Bottom Cover |
Wear Resistant Rubber |
| Cover Grade |
DIN-Y / DIN-W / Heat Resistant / Oil Resistant Grades |
| Frame |
Channel Frame / Truss Frame |
| Material Handled |
Coal, Limestone, Cement, Sand, Gravel, Minerals, Ores, Aggregates and Bulk Materials |
| Idler Arrangement |
3-Roll / 5-Roll Troughing Idler Arrangement |
| Impact Idlers |
Provided at Loading Points for Shock and Impact Absorption |
| Return Idlers |
Rubber Disc / Flat Return Idlers, as Required |
| Drive System |
Electric Motor with Geared Drive |
| Take-Up System |
Screw Take-Up / Gravity Take-Up |
| Pulley Type |
Drive Pulley / Tail Pulley / Snub Pulley / Bend Pulley |
| Splicing Method |
Hot Vulcanized Splicing / Mechanical Fasteners |
| Operating Temperature |
Typically -20°C to +80°C, Depending on Belt Compound |
| Construction |
Heavy-Duty Industrial Construction for Continuous Operation |
| Safety Features |
Emergency Pull Cord, Belt Sway Switch and Protective Guards, as Required |
| Customization |
Belt Width, Length, Speed, Capacity, Trough Angle and Drive Configuration as per Requirement |
